UL-EMA FY-170 Series

Model:EMAXXFY-170

Features :

  UL LISTED FOR US & CANADA Listed to UL924 and tested to CSA 22.2 No. 141 Field or Factory Installation

  Self-test function

  Triple protection

  Malfunction indication

  Constant Output Power

  For wiring to the led driver's AC input

  Suitable for LED products with drivers installing externally, such as led  linear high bay light, led troffer, led down light, etc.

Product Description
Input Voltage
AC100-347V
AC100-347V
AC100-347V
Ouput Voltage
DC170V
DC170V
DC170V
Output Power
15W
25W
40W
Recharge Time
≥24 Hours
≥24 Hours
≥24 Hours
Illumination Time
≥ 90Mins
≥ 90Mins
≥ 90Mins
Battery
Li-ion
Li-ion
Li-ion
Ambient Temp
0℃~ 50℃
0℃~ 50℃
0℃~ 50℃
Note: "FY" =sales code
